DPA 6060-OC-U-F10 CORE 6060 Omni Submini Mic TA4F Mini-XLR – Beige

Description

d:screet CORE 6060 Omni Submini Mic, Normal SPL. Beige, TA4F Mini-XLR connector included

d:screet 6060 CORE Subminiature Microphones are just 3 mm (0.12 in) in size but pack the audio power of our larger, award-winning DPA mics. What they lack in size, they more than make up for in clarity, consistency and durability – three qualities that really matter. By shrinking CORE by DPA technology, we ensure you don’t have to compromise on sound to focus on aesthetics.

Features

Specifications

Directional pattern:OmnidirectionalPrinciple of operation:PressureCartridge type:Pre-polarized condenserFrequency range:20 Hz – 20 kHzFrequency range, 2 dB:40 Hz – 20 kHz with 4 dB soft boost at 8 – 20 kHzSensitivity, nominal, 3 dB at 1 kHz:20 mV/Pa; -34 dB re. 1 V/PaEquivalent noise level, A-weighted:Typ. 24 dB(A) re. 20 Pa (max. 26 dB(A))S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL):Typ. 70 dB(A)Total harmonic distortion (THD):<1% up to 126 dB SPL peakDynamic range:Typ. 102 dBMax. SPL, peak before clipping:134 dBOutput impedance: From MicroDot: 30 – 40 . From DAD6001-BC:100Cable drive capability:Up to 300 m (984 ft) with DAD6001-BC XLR adapterPower supply (for full performance):Min. 5 V to max. 10 V through DPA adapter for wirelesssystems. With DAD6001-BC:48 V phantom power 4 V for full performance. Works from 12VConnector:TA4F Mini-XLRColor:BeigeWeight:8 g (0.29 oz) incl. Cable and MicroDot connectorMicrophone head size (h x w x d):3.4 / 14.4 mm (0.13 / 0.57 in)Capsule diameter:3 mm (0.12 in)Cable length:1.8 m (5.9 ft)Polarity:Positively increasing sound pressure produces positive going voltage on MicroDot pinTemperature range:-40C to 45C (-40F to 113F)Relative humidity (RH):Up to 90%
