Roland VC-1-SC Updowncross Scan Converter

Description

The VC-1-SC Up/Down/Cross Scan Converter from Roland provides high picture quality by maintaining the video characteristics of the original signal with rich-blacks and super-whites. There are no interlacing artifacts or other conversion or signal errors that are sometimes found with other video converters. The VC-1-SC also features an on-board re-clocker to compensate for attenuation of SDI signals carried over long distances. The VC-1-SC also supports both level A and B 3G-SDI, thereby enabling you to connect a variety of high quality SDI sources.

The VC-1-SC is HDCP compliant allowing you to convert or pass-through HDCP signals with the exception of any SDI output. Selectable audio embedding and de-embedding lets you route different audio sources to or from video devices. Digital AES/EBU input and output signals are supported, thereby ensuring that high-quality audio signals can be maintained through the signal flow.

SPECIFICATIONS

• Composite Video Format : NTSC, PAL
• Audio Embed/De-embed: 2-channel
• Frame Synchronization It works when enter the reference signal. When frame synchronizer is working, CH 3-8 of HDMI and CH 3-16 of SDI audio output are not available.
• Resolution Conversion Selectable Full/LetterBox/Crop/Dot-by-Dot Type
• Frame Rate Conversion Frame Skip/Repeat Type
• USB 1 x USB Type B (Hi-Speed USB)
• Power Supply 9 VDC
• Operation Temperature 32 to 104F (0 to 40C)
• Dimensions (W x D x H) 5.93 x 5.12 x 1.18″ (15.06 x 13.00 x 2.99 cm)
• Weight 1.10 lb (0.50 kg)
• Package Weight 2.4 lb
• Box Dimensions (LxWxH) 11.1 x 10.1 x 2.6″
